FEATURES

• Simultaneously displays an Ultra Hi-Def source on up to four Ultra HD displays
• Supports resolutions up to 4K@30Hz with 4:4:4 colour sampling
• Compatible with HDMI 1.4 and HDCP 1.4
• Supports PCM2.0, DTS, Dolby, LPCM Max 7.1 channel audio
• Supports 3D video
• EDID copy function for optimal compatibility

SPECIFICATIONS

• Operating Temperature Range: -5 to 35°C (23 to 95°F)
• Operating Humidity Range: 5 to 90%RH (No Condensation)
• Bandwidth Frequency: 10.2Gbps
• Input Port: 1xHDMI (female)
• Output Ports: 4xHDMI (female)
• Resolution Outputs: Up to 4K@30Hz 4:4:4
• Audio Format: PCM2.0, DTS, Dolby, LPCM Max 7.1
• Dimensions (LxWxH): 150×64.5x17mm
• Power Consumption: 1.5W (MAX)
• Net Weight: 240g
